Products
AT
Automotive Long-Range Lidar, Ultra-High Resolution
AT128
ET
Automotive Long-Range Lidar, Behind Windshield Installation
ET25
FT
Automotive Short-Range Lidar, Fully Solid State
FT120
Pandar
All-Around Performance, 360° Coverage
Pandar128
Pandar64
Pandar40P
Pandar40M
QT
Close Object Detection, Ultra-Wide View
QT128
QT64
XT
Superior Precision, Cost-Effective Solution
XT32 / XT16
Remote
Methane Leak
Detector
Faster Response, Longer Range
Handheld
Drone-Mounted
Compare
AT128
1,536,000 points/s
Point Rate
1200 × 128
Overall Resolution
200 m@10%
Range
120° × 25.4°
Field of View
137 mm × 112 mm × 48 mm
Dimensions
0.1° (H) × 0.2° (V)
Resolution
ET25
225 m @10% Reflectivity
Range (With Windshield)
120° (H) x 25° (V)
FOV
0.05° (H) x 0.05° (V)
Angular Resolution (Finest)
140 x 110 x 25 mm
Size (W x D x H)
>3,000,000 pts/s
Point Rate
12 W
Power Consumption
FT120
160 (H) x 120 (V)
Overall Resolution
100° (H) x 75° (V)
FOV
192,000 pts/s (Single Return)
384,000 pts/s (Dual Return)
Point Rate (@10 Hz)
0.1 m ~ 100 m
Instrument Range
0.625° (H) × 0.625° (V)
Angular Resolution
Typ.10 Hz
Frame Rate
Pandar128
128
Channel
3,456,000 pts/s (Single Return)
6,912,000 pts/s (Dual Return)
Point Rate
0.1° (10 Hz)
Horizontal Resolution
0.3 ~ 200 m*
* 10% reflectivity, 100 klux, PD>70%, FAR<1e-5
Range
Finest at 0.125°
Vertical Resolution
Pandar64
64
Channel
0.3 ~ 200 m (10% reflectivity)
Range
40° (-25° ~ +15°)
Vertical FOV
0.2° (10 Hz) , 0.4° (20 Hz)
Horizontal Resolution
Finest at 0.167°
Vertical Resolution
Pandar40P
40
Channel
0.3 ~ 200 m (10% reflectivity)
Range
40° (-25° ~ +15°)
Vertical FOV
0.2° (10 Hz) , 0.4° (20 Hz)
Horizontal Resolution
Finest at 0.33°
Vertical Resolution
Pandar40M
40
Channel
0.3 ~ 120 m (10% reflectivity)
Range
40° (-25° ~ +15°)
Vertical FOV
0.2° (10 Hz) , 0.4° (20 Hz)
Horizontal Resolution
Finest at 0.33°
Vertical Resolution
QT128
128
Channel
20 m (10% reflectivity)
Range
105.2° (-52.6° ~ +52.6°)
Vertical FOV
Finest at 0.4° @10 Hz
Horizontal Resolution
Finest at 0.4°
Vertical Resolution
QT64
64
Channel
20 m (10% reflectivity)
Range
104.2° (-52.1° ~ +52.1°)
Vertical FOV
0.6°
Horizontal Resolution
Finest at 1.45°
Vertical Resolution
XT32 / XT16
32
Channel
0.5 cm (1σ precision)
Range Precision
0.05 ~ 120 m*
Range
1°
Vertical Resolution
31° (-16° ~ +15°)
Vertical FOV
16
Channel
0.5 cm (1σ precision)
Range Precision
0.05 ~ 120 m*
Range
2°
Vertical Resolution
30° (-15° ~ +15°)
Vertical FOV
Handheld
200 m (82% diffuse reflectivity,
15000 ppm*m methane gas concentration)
Detection Range
5 (actual) ppm*m
Sensitivity
±10% (100 ~ 50000 ppm*m)
Measurement Accuracy
5 ms
Response Time
0.76 kg
Weight (with battery and sight)
Drone-Mounted
400 m (82% diffuse reflectivity,
15000 ppm*m methane gas concentration)
Detection Range
5 (actual) ppm*m
Sensitivity
±10% (100 ~ 50000 ppm*m)
Measurement Accuracy
5 ms
Response Time
<600 g
Weight

中/ EN

Latest News

Type

Tags

Dates

Hesai’s AT128 Automotive Lidar Debuts in Europe with Luxury EV HiPhi Z’s German Sales Launch

Hesai’s AT128 lidar will be at the core of the Human Horizons HiPhi Z’s Advanced Driver Assistance Systems (ADAS).

2023-09-05

Hesai and Webasto Collaborate on Lidar Integration on Roof Sensor Module for ADAS

ADAS AT128 ET25

Hesai will provide automotive lidar sensors to Webasto for its Roof Sensor Module for passenger cars with ADAS.

2023-09-03

Polestone 01 Officially Debuts - The World's First Vehicle Model to Feature Hesai's Cutting-Edge Fully Solid-State Lidar

Polestone 01 was officially released on August 22. Its features a long-range lidar - AT128, and two blind-spot fully solid-state lidars - FT120.

2023-08-29

Events and Tradeshows

Hesai to Showcase Its High-Performance Automotive Lidar Sensors at IAA Mobility 2023

ADAS AT128 ET25 FT120

Hesai Technology will showcase their high-performance sensors at IAA Mobility 2023 in Munich.

2023-08-17

Hesai CEO David Li Sat Down With Automotive News Executive Editor Jamie Butters for His Daily Drive Podcast

A conversation with David Li, co-founder, and CEO of Hesai Technology, which has quickly become one of the largest lidar companies in the world.

2023-08-03

Hesai Technology Advances Autonomous Vehicle Lidar Integration with NVIDIA DRIVE and Omniverse

By combining Hesai’s industry-leading expertise in lidar sensors with NVIDIA’s AI, simulation, and software development platforms, the collaboration will unlock new possibilities for the autonomous driving industry.

2023-08-01

Forbes: Hesai Dominates The Automotive LiDAR Market

ADAS ET25 Home News Robotaxi

We are thrilled to be featured in the Forbes magazine regarding the future of lidar in the automotive market.

2023-07-26

Hesai Ranks No. 1 in Global Automotive Lidar for the 2nd Year in a Row

ADAS Autonomous Vehicles Home News

Lidar expert Yole Group highlights Hesai’s record-breaking revenue and shipments

2023-07-25

Working Group Led by Hesai Experts Makes Key Progress in Global Automotive Lidar ISO Standardization

Hesai experts presented their pre-research results on the global ISO standardization of automotive lidar.

2023-07-20

The Top 4 Autonomous Vehicle Trends in 2023

What does the future have in store for autonomous vehicles? What technologies are making waves now? Discover these top autonomous vehicle trends for 2023.

2023-07-17
